2001 gtp special edition

[[ChaosweaveR]]

Tire bags FTW.

[markpetersonii]

' timestamp='1326939858' post='65247']

Tire bags FTW.

Those things are so weird. Wait... we are talking about the same thing right?

/>http://www.youtube.com/watch?v=WYjIDvSdzHQ&feature=player_embedded

[[ChaosweaveR]]

Oh lul...

[killerspeed101]

Im getting code p0620 which is Generator Control Circuit Malfunction . my batt is being drained when its running. i have maybe 3-5 min before she starts stalling. any ideas on what it could be?

[havoc1482]

P0620

Description

Generator Performance

The power control module (PCM) output (L) terminal to the alternator determines when the alternator will be turned off. The alternator is on under all normal vehicle operating conditions except during the low RPM conditions. The alternator is turned off during low RPM conditions in order to remove the load from the engine.

The PCM input field (F) terminal from the alternator provides a 400 Hz pulse-width modulated (PWM) signal to the PCM. The duty cycle of the F terminal mimics the duty cycle of the field coils in the alternator, thus, the F terminal duty cycle indicates the relative electrical load on the alternator.

The alternator telltale lamp will illuminate any time the ignition is on and the engine is not running. The telltale lamp will turn off after the engine is running and the alternator is putting out the desired amperage.

Symptoms

• The PCM will not illuminate the malfunction indicator lamp (MIL).

• The PCM will store the conditions, which were present when the DTC set as Failure Records Data only. This information will not be stored as Freeze Frame data.


Causes

• The L terminal voltage is low while the PCM is commanding the generator on.

• The above condition is present for more than 30 seconds.


-OR –

• The F terminal PWM is less than 5 percent.

• The engine RPM is less than 2500

• The above conditions are present for more than 30 seconds.


Solutions

Check for the following conditions:

• A faulty connection at the PCM – inspect the harness connectors for backed out terminals, improper mating, broken locks, improperly formed or damaged terminals, and faulty terminal to wire connections.

• Inspect the wiring harness for damage.

• Several steps prior to below require a Scan tool to command the generator on and to verify voltage which may indicate a problem with the starting and charging engine electrical system.

• Test the L circuit for a short to voltage. Were problems found?

  • YES – Repair as necessary and clear DTC

  • NO - Test the F circuit for an open or a short to ground. Were problems found?

    • YES – Repair as necessary and clear DTC


    [*]NO - Test the F circuit for a short to voltage. Were problems found?

    • YES – Repair as necessary and clear DTC

    • NO – Check for a faulty connection at the PCM. Were problems found?

      • YES - Repair as necessary and clear DTC

      • NO – Replace the PCM.


[killerspeed101]

Nvm car is running fine now. i swear this car is trolling me.

[havoc1482]

Should proably still check out the P0620 code though lol

[killerspeed101]

Should proably still check out the P0620 code though lol

im going to.

[red97GPGT]

try the p0102 code.... i got that little gem early last week when the car stalled out at 70mph on the interstate, 3500lb sled anyone. You get that code, dont dick with it, just replace the damn thing. lol

[killerspeed101]

try the p0102 code.... i got that little gem early last week when the car stalled out at 70mph on the interstate, 3500lb sled anyone. You get that code, dont dick with it, just replace the damn thing. lol

do u have a k&n air filter?

[killerspeed101]

i got some gtp grill badges and rear pontiac overlay on the bumper. the best part is that i got both freeee

[Ghost]

cant beat free!

[killerspeed101]

Im putting my tranny in thurs . any tips or instructions?

[havoc1482]

Im putting my tranny in thurs . any tips or instructions?

Don't f*ck up

[killerspeed101]

Don't f*ck up

[havoc1482]

[[ChaosweaveR]]

Dat rock.

[Ghost]

Don't f*ck up

[Jedi3]

cant beat free!

That's what Jim says every time he thinks of paying us Ghost.

[killerspeed101]

That's what Jim says every time he thinks of paying us Ghost.

[Ghost]

That's what Jim says every time he thinks of paying us Ghost.

...oh...

[killerspeed101]

Dat A$$

[red97GPGT]

Dude tint them tails! Quick question though, what are your thoughts on running a 5x114.3 wheel vs 5x115, i hear the fit with little to no issues.

[killerspeed101]

Dude tint them tails! Quick question though, what are your thoughts on running a 5x114.3 wheel vs 5x115, i hear the fit with little to no issues.

i know. they fit fine so i would run them

[killerspeed101]

Tommorow is the big day. cant wait!!!
